Electronic equipment connection diagram
When the battery of the transmitter is low, the red indicator of the transmitter will flash slowly. When the
car battery is low, the transmitter green indicator light flashes. The battery should be replaced as soon
as possible to avoid accidents.
When the signal is weak or the signal is interrupted, the red indicator of the transmitter will flash quickly.
Please operate within the effective control distance to avoid accidents.
6>
5>
1>
Replacement of parts
Low battery alarm
Replace the ESC
Weak signal alarm
Pull out all the plugs and remove the ESC upward. Replace with a new ESC.
Front
Steering servo
Li-ion battery
Integrated ESC
Power switch
Headlight
Taillight
Motor
Front
