SCHEMA ELETTRICO
WIRING DIAGRAM
SCHEMA ELECTRIQUE
SCHALTSCHEMA
ESQUEMA ELECTRICO
1/5-8 - 2/5-8 - 3/5-8
1 Interruttore Switch Interrupteur Schalter Interruptor
2 Termostato Thermostat Thermostat Thermostat Termostato
3-5 Pompa/agitatore Pump/mixer Pompe/brasseur Pumpe/Rührwerk Bomba/agitador
4 Compressore Compressor Compresseur Kompressor Motocompresor
4/5-8
1 Interruttore Switch Interrupteur Schalter Interruptor
2-3 Termostato Thermostat Thermostat Thermostat Termostato
4-6 Pompa/agitatore Pump/mixer Pompe/brasseur Pumpe/Rührwerk Bomba/agitador
5 Compressore Compressor Compresseur Kompressor Motocompresor
