18
described below should be considered general in nature and
may vary due to the health regulations in force.
2 Before disassembly for washing, the dispenser must be
emptied out of the product. Proceed as follows:
- use the keypad to select the CLEANING operating mode
- if necessary, wait until the product becomes liquid
- place a container under each tap and empty the containers
- fill the containers with water and allow the dispenser to
operate in CLEANING mode for a few minutes. Then empty the
containers.
- hold down key A to switch off the dispenser
- turn the ON/OFF SWITCH to OFF
7. 4. 1 DISASSEMBLING THE RECOVER (OP-
TIONAL)
1 Place the right-hand part of the recover on a surface. Place
the container inside it.(see figure 2)(see figure 3).
figure 2
figure 3
2 Put the left-hand part of the recover into position and make
sure that it fits into the illustrated groove. Click the two parts
together. (see figure 4)(see figure 5).
figure 4
figure 5
7. 4. 2 DISASSEMBLY
1 To remove the lid of the container, press the top button and
slide the lid towards the front of the container.
If there is a safety lock for the lid, turn the key in an anti-
clockwise direction to release the open button (see figure 6).
figure 6
2 To remove the container, push the lever upwards (see
ATTENTION
Before disassembling any component, always unplug
the device from the mains.
