18
the container inside it.(see figure 2)(see figure 3).
figure 2
figure 3
2 Put the left-hand part of the recover into position and make
sure that it fits into the illustrated groove. Click the two parts
together. (see figure 4)(see figure 5).
figure 4
figure 5
7. 4. 2 DISASSEMBLY
1 To remove the lid of the container, press the top button and
slide the lid towards the front of the container.
If there is a safety lock for the lid, turn the key in an anti-
clockwise direction to release the open button (see figure 6).
figure 6
2 To remove the container, push the lever upwards (see
ATTENTION
Before disassembling any component, always unplug
the device from the mains.
