UHPPOTE HBK-RW01 - Specifications; Receiver Specifications; Transmitter Specifications

EN
Exit Button Output Port: 1
Operating Method: RF Remote and WiFi
Operating Voltage: 12VDC
Operating Environment: Indoor
Specifications
Lock Output Port: 1
Keypad Connection Port: 1
RF Channel: 1
WiFi Standard: 2412-2462MHz
Receiver
RF Frequency: 433.92MHz
Output Current: 1A
Transmitter Support: Max. 40
Built-in Buzzer: Yes
DC Encoding Type: Learning Code
Time Delay: 0/5/10 seconds
Ambient Temperature: -22°F to 140°F
Enclosure Material: ABS Plastic
Dimensions: 3-37/64"x 2-21/64"x 1-9/64" [91x59x29mm]
Operating Distance: 164 feet without block
Operating Mode: Momentary/Toggle/Latched
Operating Current: 10mA
Enclosure Material: ABS Plastic
Batteries Type: CR2016 (Built-in)
Transmitting Frequency: 433.92MHz
Operating Voltage: 6VDC (Powered by 2pcs CR2016 batteries)
Transmitter
Ambient Humidity: 0%RH-95%RH(Non-condensing)
