ULTIMATE SPEED UPK 10 E2 - Page 19

19GB/IE/NI/CY/MT
Step LEDs Meaning /
Error
Solution
1. Connect the
jump lead
18
of the power
bank with
compressor
1
to the car-
jumpstart-outlet
8
of the
power bank
with
compressor
1
.
Red Error LED
20
is
continuously lit on
the jump lead
18
.
The voltage
determined in
the power bank
with compressor
1
is not enough
to start the car.
Charge
the power
bank with
compressor
1
.
Green Start LED
19
and the red
Error LED
20
flash
alternately.
Power bank with
compressor
1
ready.
Carry on to
step 2
2. First connect
the red
clamp
(A) to the
positive pole
of the vehicle
battery and
then connect
the black bat-
tery clamp (B)
to the negative
pole (see
Fig. 1).
The red Error
LED
20
flashes,
a short alarm
signal sounds.
The tempera-
ture is too high,
possibly due to
several jump
start attempts.
Disconnect
the black (B)
battery clamp
first and then
the red clamp
(A) from the
battery poles.
Start again
from step 1.
The red Error
LED
20
flashes, a
continuous alarm
signal sounds.
Battery clamps
(A) and (B) are
the wrong way
round.
It is caused by
a short circuit
or the battery is
leaking.
The red Error LED
20
flashes once,
a continuous alarm
is sounded and
then followed by
two short alarm
sounds.
Green Start LED
19
and the red
Error LED
20
flash
alternately. After
1–2 seconds only
the green LED
19
glows.
The connection
is correct.
Carry on to
step 3
3. Starting up the
vehicle.
