Ultimate T32160 - Page 13

T
3 5600
1. Power L.E.D 2. Line level input 3. Input level adjust
4. High pass freq. adjust 5. Low pass freq. adjust
6. Protection L.E.D. 7. Crossover select 8. Sub- sonic freq switch
1 2 2 3 4 3 4 3 5 2 6
7 7 7 8
1. Fuses 2. Power terminals 3. Speaker terminals
1 2 3
