Ultrafly Edge 540 - Tail & Landing Gear Assembly

05
TAIL & LANDING GEAR ASSEMBLY
Procedure 1
Procedure 2
Procedure 3
7.5mm7.5mm
19mm 19mm
15mm
90
o
38mm
Take out the elevator from fuselage. Use hobby knife to remove the film in the center section
between the markings for future assembly as picture shows.
