Ulvac GP-1000G User Manual (English)

Questions and Answers:

P
Paul MoranAug 5, 2025
Why does the Ulvac GP-1000G pressure display not show a constant value?
- D
  David SingletonAug 5, 2025
  Several factors can cause the pressure display to fluctuate. The pressure itself might be changing, or the sensor head could be the wrong type. Contamination or wear of the sensor head filament can also lead to inconsistent readings. Check for leaks in the sensor head or the installation area. Poor contact in the sensor head cable or corrosion in the wire rod can also be culprits. If there is a leak in the sensor head, replace it; otherwise, stop the leak. If the sensor head is not of the specified type, replace it or readjust and recalibrate the one currently in use. If the sensor head is contaminated or the filament has worn out, replace the sensor head. For the sensor head cable, inspect it.
Y
ysharpAug 13, 2025
What to do if the Ulvac GP-1000G Measuring Instruments display remains blinking at E.E × 10[E]?
- R
  Rebecca QuinnAug 13, 2025
  If the display blinks at E.E × 10[E], it could mean several things. First, the sensor head filament may have burnt out; check it for continuity (the filament resistance value should be about 13 ohms under atmospheric pressure). Replace the sensor head if the filament is burnt. Avoid energizing the filament with a current of 10 mA or more to prolong its life. Also, the sensor head filament might be disconnected or have poor contact, so check the sensor head cable. Finally, ensure that the sensor head, measuring unit, and sensor head cable are securely connected to the controller.
S
Sandra UnderwoodAug 20, 2025
What to do if the Ulvac GP-1000G Measuring Instruments display does not blink at 2.7 × 10[+3] Pa when measuring atmospheric pressure?
- W
  Wendy WardAug 21, 2025
  If the display doesn't blink at 2.7 × 10[+3] Pa during atmospheric pressure measurement, the sensor head type might be incorrect; replace it with the specified type, or readjust and recalibrate the current one. Alternatively, the sensor head might be contaminated, or the filament could be worn out, requiring sensor head replacement. High air temperature at the sensor head or controller location can also cause this issue; relocate the installation to a clean, well-ventilated area away from drafts.
J
Jennifer JosephAug 28, 2025
How to troubleshoot no display on Ulvac GP-1000G front panel?
- E
  Erica HarveyAug 28, 2025
  If there's no display on the front panel when you turn on the power, first check the power cord to ensure it's properly connected. If the cord is fine, use a circuit tester to check the line voltage; it might be below the specified range.

Ulvac GP-1000G Specifications

General

Brand	Ulvac
Model	GP-1000G
Category	Measuring Instruments
Language	English

Summary

Introduction and Safety Guidelines

Prior to Use Checklist

Essential checks and information before operating the vacuum gauge.

Safety Symbols and Cautions

Explanation of safety symbols and detailed precautions for safe operation and handling.

Operational and Environmental Safety

Precautions for operating conditions, impact, repacking, disposal, and component care.

Overview and Component Identification

Product Specifications

Details technical specifications including measurable range, accuracy, and power requirements.

Standard Accessories

Lists the standard accessories included with the vacuum gauge.

Optional Components

Details optional components like sensor heads, measuring units, and cables.

Controller Component Descriptions

Describes the front panel, rear panel, and LCD display of the controller unit.

Installation Procedures

Preparation and Controller Mounting

Covers preliminary checks, unpacking, and controller installation steps.

Sensor Head Mounting and Electrical Connection

Guides on sensor head installation, electrical connections, and specific mounting methods.

Operating the Vacuum Gauge

Handling Cautions

Lists important precautions for handling the vacuum gauge during operation.

Settings and Display Interpretation

Explains DIP switch settings and how to interpret out-of-range pressure displays.

Setpoint Relay Outputs

Details setpoint activation, error indications, and relay actions.

External Interfaces and Communication

I/O Connector and BCD Output

Details I/O connector assignments and BCD output data format.

Strobe Signal Characteristics

Describes the strobe signal timing and equivalent circuit used with BCD output.

Recorder Output Signals

Linear Output Signals

Details linear voltage outputs for different pressure ranges (1.0x10³ Pa and 1.0x10² Pa).

Log and Non-Linear Outputs

Explains dummy log and non-linear output characteristics and their conversion to pressure.

RS-232C Communication

Specifications and Cable Connection

Lists communication specifications and how to connect the RS-232C cable.

Commands and Actions

Details available commands and expected responses for RS-232C operation.

Appendix: Technical Information

Principles of Operation

Explains the thermal conduction mechanism of the Pirani vacuum gauge.

Gas Type and Temperature Effects

Discusses gas type influence and ambient temperature effects on readings.

Troubleshooting Guide

Display and Pressure Reading Issues

Addresses no display, blinking, incorrect low pressure, and unstable readings.

Specific Operating Condition Problems

Covers issues related to atmospheric pressure readings and overall stability.

Warranty and Disclaimer

Warranty Coverage and Procedure

Details the warranty period, scope, and required response procedures.

Warranty Exclusions

Lists conditions and events that are explicitly excluded from warranty coverage.

CE Declaration of Conformity

EMC and Immunity Standards Conformance

Lists the EMC emission and immunity standards the instrument adheres to.

China RoHS Declaration

Hazardous Substance Compliance

Details compliance with hazardous substance limits for product components.

Certificate of Decontamination

Decontamination for Service

Specifies requirements for certifying decontamination before submitting for repair.

Dimensional Drawings

Controller and Sensor Drawings

Provides dimensional drawings for the controller and various sensor heads.
