8
Installation
1. Select a level surface that provides enough open space for the intake and/or outlet vents.
Min. 85cm
20cm
0cm
30cm
20cm
a. The minimum installation height is 85 cm.
b. The rear surface of the appliance should be placed against a wall.
Leave a minimum clearance of 30 cm above the oven. A minimum clearance of 20 cm is
required between the oven and any adjacent walls.
c. Do not remove the legs from the bottom of the oven.
d. Blocking the intake and/or outlet openings can damage the oven.
e. Place the oven as far away from radios and TVs as possible. Operation of the microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Make sure the voltage and the frequency are
the same as the voltage and the frequency on the rating label.
Do not install the oven over a range, cooktop, or other heat-producing
appliances. If installed near or over a heat source, the oven could be damaged
and the warranty would be void.
WARNING
The accessible surface may be hot during operation.
WARNING
To Next Page
