UNI-T UT212 - AC Voltage Accuracy

B. AC Voltage
Range Resolution Accuracy RemarksOverload
Protection
4V
40V
400V
1mV
10mV
100mV
(1.2%+5)
(1.5%+5)
60V
1V 600V
Input impedance:
Full auto measurement mode:
When Vx 5V, it is around
10M .
When Vx > 5V, it instantly
transits from 1k to 10M .
At high impedance mode:
around 10M High impedance
is mode is 10M .
Displays effective value of sine
wave (mean value response).
Frequency response:
50Hz~400Hz.
Testing sensitivity:
AC 1.5V
Model UT212: OPERATING MANUAL
23
