UT501/UT502 OPERA
TING MANUAL
T
able 3. Meter Front Description
EARTH: Resistance input terminal
G: V
oltage Measurement input negative terminal
V
: V
oltage input terminal
LINE: Resistance input terminal
LCD
Display Backlight button
Data Hold button
Insulation Resistance Button
Rotary switch
1
2
3
4
5
6
7
8
9
12
14
