Model UT513: OPERATING MANUAL
General Specifications
Range
Overloading
Battery Indicator
Icon Display
Current Consumption
Auto
Display OL on insulation resistance range
Display
Equips with function and battery indicator icons.
Maximum: around 1.0A
Average: around 20mA
Feature Summary
Display Backlight
Computer connection
Data Logging and Recall
Autorange
Warning
Voltage
COMP Measurement
PI Measurement
TIME
Bright backlight for clear readings in poorly lighted areas.
Via USB interface.
18
The Meter automatically selects best range
and red light will on.
Auto release voltage
Use the Compare function to set a pass/fail compare level for the insulation
measurements.
Polarization Index is the ratio of insulation resistance. You can pre-set two
point of times and automatically carry out the measurement.
To carry out measurement by setting a specified time within 15 minutes.
