Unic URW295CR - Slide Plate and Guide Installation

(4) Ins tallation procedures for s lide plate and guide
It has s imilar cons truction irres pective of number of boom s ection
C learance 1mm
C learance 2mm
When assembling,
apply"Lock tight #242".
S lide plate
G uide
（１３−４）
