(7) Adjus ting P rocedures for S elector V alve with Adjus ting B olt
Adjus ting P rocedures with Adjus ting B olt
Retract telescoping cylinders (1) and (2) to their minimum.
Apply ÒL OCK TIGHT 242Ó to the threads of the adjusting bolt.
Put a board with a thickness of 3mm to the part marked with*.and tighten the adjusting bolt.
After adjusting, lock with the lock nut.
