Unic URW295CR - Turntable Mounting; Turntable Mounting Procedures

Flame
２０．１ TurntableMountingProcedures
１ Installtheslewingreductiongeartothebase.
２ Settheturntableonthebasetoscrew‑intheboltsformountingturntablelightly.
３ Insertthethicknessgauge(0.1〜0.2mm)intothespacebetweentheturntablegear
andthepiniongear,andpressstronglytheturntabletothepiniongear.
４ Soasnottopartfromtheturntableandthepiniongear,ittightenswiththe
specifiedtorqueintheorderoftighteningtheinstallationbolt.
５ Afteritassemblesit,greaseispaintedonthegeartoothcombinationside.
S
Back Front
"Ｓ"Mark(Softzone)Position
Temperedbolt
Slewingreduction
gearass'y
Bolt
Piniongear
Turntable
Afterassembling,
applygreaseto
engagingtooth
surfacesofthegears.
（２０−１）
Tightingsequenceofboltformountingturntable
Tightnentheboltsinthenumericalorderas
illustratedinthefigureabove.
１
２
３
４
５
６
７
８
９
10
11 12
13
14
15
