18
Installation info
fig. 17
fig. 18
_
>
500
Example N.1
Hmin. = 150 mm
CONFIGURAZIONI RELATIVE ALLE TUBA-
ZIONI SIA DI SCARICO CHE DI ASPIRAZIO-
NE Ø 80
DIMENSIONS FOR CONNECTING THE AIR INTAKE AND THE FLUE GAS DISCHARGE
WITH DUAL DUCTS
Example N.1 (fig. 18)
Primary air suction from perimeter wall and
flue gas discharge on roof.
Maximum allowable pressure loss:
50 Pa (IVEN 04 TFS 24)
60 Pa (IVEN 04 TFS 28)
85
85
245
Ø 80
85
160
245
85
85
85
85
