unication G5 User Manual

8
▀
Every Receiving Table can be set with the following parameters by PPS in accordance with the users'
requirements to satisfy the users' needs.
G
H
Pager Status operate on customer's radio system
Pager operate on different
system Receiving Table
Setting
Settings of the end of Message
Note: There are 2 ways of how the calls ended
1. Receiving ends after receiving the Ending
Code.
2. Delay N, that it will be ended after a period of
time (users can set the time when there are
no signal. (Ending Code will not be
transmitted in this setting under the
conventional system. It must take the time,
which has no signal received, as an
activation of turning off the speaker, but it is
afraid that is the Hand Time during the
conversation. Therefore, Delay N is used to
handle this. )
Protocols used by each receiving frequency
Settings
( Note：There are 3 types of settings for selecting the
protocols used by every communicating frequency)
1. Every frequency is allowed to be set with one
protocol. The options of protocols are as
follows:
(a) Analog Signal
(a1) CSII (a2) Two-Tone
(a3) 5-Tone (a4) MDC
(a5) CTCSS (a6) CDCSS
(b) Digital Signal
(b1) DMR (b2) P25C
(b3) P25 / Phase#1 (b4) P25 / Phase#2
2. Every frequency can set up Auto Detection
(one of the Analog protocol, and one of the
Digital protocol; The assigned protocols can
be alternated Analog with Digital, however,
there are only some of them cannot be
occurred colaterally.
(1) CT or CD (only one of them can be
chosen)
(2) 2-Tones or 5-Tones (only one of them can
be chosen)
(3) DMR and P25C
(4) P25 Phase#1 and Phase#2), it represents
that it is able to detect the protocol used by
the signal in the air with the device itself, and
based on that protocol to decode and
demodulate.
3. Auto Detection (no additional assigned
protocols) this condition will delay receiving
and it is commonly used with Free Scan
(Scanner)
Set up the protocols used by
the each channel.
Set up the protocols used by
the each channel.
Set up the protocols used by
the each channel.
Multi-frequency priority
scan mode
Single frequency
Receiving Mode
Multi-frequency priority
scan mode
Set up the receiving end
message condition of each
channel
1. Normally the time set
should be longer than the
Hang Time, read the
Selective Code after
that.(That means when
there is a TGID, which is
designated to listen, the
speaker will be turned on.)
1. Set up the ways how should
the Priority channel end, 2
types of castcode settings
are provided, Ending code
will be the first. Once the
Ending code has not been
received, Delay N will be
enabled. (i.e. the device will
be switched to Standby
mode automatically, when
there is no message
received during the time set.)
2. It is not necessary to set the
way how should the signal
end for Secondary
frequency. (Since it will
switch back to Priority
frequency once it is the Stay
Time, no matter there is any
signals or not.
1. Set up the ways of how
should the receiving end for
every Scan frequency.

unication G5 Specifications

General

Water Resistance	IP67
Frequency Bands	VHF, UHF, 700/800 MHz
Battery Type	Li-Ion
Alert Types	Vibration, Tone
Protocols	P25 Phase 1 & 2
Modulation	C4FM
Operating Temperature	-30°C to +60°C
