Electrical Installation 4-9
Figure 4-5—1120 Power and Grounding Connections
Form 12N
Dynamic
Braking
Resistor
(optional)
AC
Motor
PE
DC Bus
PE PE R S T PE U V W B+ DB B—
Form 17
SR T VU W DBB+ B—
PE PEPE
