Transport, packaging, storage
PG-I Series | Version 1.03 7
4.1 Type plate
Fig. 2: Type plate PG-I 35 SE
5 Transport, packaging, storage
Delivery
Check the generator after delivery for visible transport
damage. If you discover any damage to the generator,
report this immediately to the transport company or the
dealer.
Transport
Generator IP de-
gree of protection
IP 23M IP 23M
Socket type 1x230V,
DC12V,
4.0A
1x230V,
DC12V,
4.0A
Socket IP degree
of protection
IP54 IP54
Output max. drive
motor
0,9 kW 1,3 kW
Starter Hand launch Hand launch
Fuel Gasoline Gasoline
Tank capacity 2,1 Liter 3 Liter
Running time at
50% load
6,1 Std. 6,6 Std.
Running time at
100% load
4,1 Std. 4,4 Std.
Speed 3800-5000
rpm
3600-4800
rpm
Sound pressure
level
67 dB(A) 70 dB(A)
Weighted sound
power level (LWA)
93 dB(A) 93 dB(A)
Model PG-I 20 SR PG-I 35 SE
Length 525 mm 614 mm
Width / depth 282 mm 341 mm
Height 457 mm 506 mm
Net weight 18,5 kg 37,5 kg
Nominal voltage 230 V 230 V
Max. voltage de-
viation (+/-)
±3% ±3%
Limited output po-
wer (active power)
1,8 kW 3,1 kW
Continuous out-
put power (active
power)
1,7 kW 2,8 kW
Generator IP de-
gree of protection
IP 23M IP 23M
Socket type 2x 230V,
DC12V,
5.0A
2x 230V,
DC12V,
5.0A
Socket IP degree
of protection
IP54 IP54
Model PG-I 8 SR PG-I 12 SR
Output max. drive
motor
2 kW 4 kW
Starter Hand launch E-Start
Fuel Gasoline Gasoline
Tank capacity 4,1 Liter 7,5 Liter
Running time at
50% load
5,7 Std. 6,1 Std.
Running time at
100% load
3,8 Std. 4,1 Std.
Speed 3300-4500
rpm
3600-4800
rpm
Sound pressure
level
70 dB(A) 73 dB(A)
Weighted sound
power level (LWA)
93 dB(A) 96 dB(A)
CAUTION!
Injuries caused by parts falling over or off a forklift,
pallet truck or transport vehicle.
Only use means of transport that can carry the total
weight and are suitable for it.
Model PG-I 20 SR PG-I 35 SE
