3
REAR
NO. DESCRIPTION NO. DESCRIPTION
1 Mounting Base 7 Memory Card Slot
2 Back Case 8 Power Supply
Interface
3 Sun Shield 9 10/100M Self-
Adaptive Ethernet
Interface
4 Lens 10 PoE Cable
5 Adjusting Nut 11 GND Screw
6 WPSS/RESET Button
INSTALLATION
CONSIDERATIONS
• Make sure the device in the package is in good condition and all the
assembly parts are included.
• The standard power supply is 12VDC (±25%) or PoE (802.3 af). Verify
that your power supply matches your camera.
• Make sure all the related equipment is o during the installation.
• Make sure that the wall or ceiling is strong enough to hold the weight
of the camera and the base.
To Next Page
