Page #19 background imageLoading...
Page #19 background image
General
Channels Transmit 40 (with Duplex Channel Support)
Receive 40
Oper. Temp. 0˚C - +55˚C
Antenna Flexible Whip
Microphone Built-in Electret type
Display Liquid Crystal Display
Speaker 8 1 Watt
Power Source BP-052
Rechargeable Nickel-cadmium
Battery Pack
950mAh, 7.2V
Size (without antenna) 150(H) x 55(W) x 40(D)mm
Weight 450g (with Antenna & Battery Pack)
Transmitter
Frequency Control Phase Locked Loop
Frequency Range 476.425 to 477.4 MHz
Frequency Stability ±6 ppm
Power Output 5W (high)/ 1W (low)
Spurious Emissions -65 dBc
Current Drain 1500mA (High)/650mA (low)
Receiver
Receiver Type Dual Conversion
Super Heterodyne
Phase Locked Loop
System for Local Oscillator
Frequency Range 476.425 to 477.4 MHz
Sensitivity @ 0.22 µV
12 dB SINAD
Squelch Sensitivity 0.19 µV (Threshold)
Audio Frequency
Response 500Hz, 4.5dB
(ref: 1KHz, ± 3KHz Dev.) 2000Hz, -6.5dB
Adjacent Channel 55 dB
Selectivity
Hum & Noise Ratio 40 dB
Audio Output Drain 0.3W (10% THD)
Current Drain
Squelched 35 mA
Max.Audio 150 mA
SPECIFICATIONS
16
