Operation
To Transmit and Receive
TheUH036SX-2NBusestheUHF-CBChannels.Refertopage9forUHF
channelusage.(Channels22and23arefortelemetryandtelecommand
applications.Transmitisinhibitedonthesechannels).
1. Thetransmitpowerofthe
  UH036SX-2NBis500mWwhichwill
  providearangeofupto3+Km.
2. Beforeyoutransmit,listenfor
  activityontheselectedchannel.
3. Whenthechannelisclear,pressandholdthe

  totransmit.TXappearsontheLCD.
Holdtheradiowithmicrophoneapproximately5cmin
frontofyourmouthwiththeantennaatapproximately45°
angleawayfromyourhead.Speakinaclear,normal
conversationalvoice.
4. Whenyouhavenishedspeaking,
  releasethe
.TXthendisappearson
  theLCD.Listenforaresponse.
5
UHFCBTransceiverUNIDENUH036SX-2NB
mic
vol/
mon
ch/
scan
dup
mic
vol/
mon
ch/
scan
dup
PTT
Switch
TX
NOTE
Formaximumrangeandextendedthelifeofthebatteries,
avoid touching the antennawithyourhandwhentransmitting.
PTT
switch
