Page #19 background image
19
Forestry winches – 35M / 40eco (Image 2)
Pos.
Title
Nr. of pcs
Plan or standard number
1
Pre-brake screw
1
702.00.41.0
2
Brake wire 5,5 m kpl (red)
1
1000554
3
Clutch wire 6.5 m kpl. (black)
1
1004067
4
Small single pulley
1
502.00.40.0
5
Small double pulley
1
502.00.41.0
6
Small single pulley 2
1
502.00.42.0
7
Small double pulley, wide
1
502.00.43.0
8
Spacer tube
1
502.05.12.0
9
Pin 1
1
502.06.08.0
10
Brake bolt
1
502.06.12.0
11
Brake fork
1
502.06.15.0
12
Brake handle var.
1
502.06.20.0
13
Clutch lever spring
1
502.06.25.0
14
Lever plate 1
2
502.06.30.0
15
Brake sleeve
1
502.06.32.0
16
Brake compression spring
1
502.06.35.0
17
Brake bolt
1
502.06.41.0
18
Compression spring
1
702.69.00.0
19
Washer
1
1000363
20
Braking belt spring
1
502.06.07.1
21
Brake roller
3
502.11.15.0
22
Clutch lever spring
1
502.11.25.0
23
Automatic control mechanism actuator var.
1
502.11.30.0
24
Automatic control mechanism kpl.
1
502.50.00.0
25
Clutch handle var.
1
303.12.00.0
26
Brake band var.
1
305.06.00.0
27
Pad
2
305.06.04.0
28
Brake tubing
1
305.06.07.0
29
Screw hexagon M8x16
2
1003454
30
Control mechanism housing var.
1
502.50.02.0
31
Extension spring
1
502.34.01.0
32
Actuator housing 1
1
502.50.06.0
33
Return rod
1
502.50.09.0
34
Ball fi 8,7
2
1010486
35
Spring linchpin 6x40
1
1000208
36
Screw M8x70 Zn
1
1000042
37
Screw M8x55 Zn
1
1000041
38
Screw M6x35 Zn
1
1000040
39
Screw M8x20 Zn
4
1000051
40
Screw M8x25 Zn
2
1000052
41
Screw M10x45 Zn
1
1000075
42
Screw M8x60
1
1001147
43
Nut M8x60
7
1003460
44
Nut M6 Zn
1
1003712
45
Nut M10 Zn
1
1003461
