Uniforest 35M User Manual

3
2. Intended purpose
The machine is intended exclusively for normal work in the forest. Any other use outside of this
framework holds as unintended. The manufacturer is not liable for damages, resulting from
unintended use. In this case, the user is the sole bearer of risk. Intended use also includes
regarding operational, service and maintenance conditions, which are prescribed by the
manufacturer. Only persons, who are trained and acquainted about the dangers and
consequences, which can result from improper use, can operate the machine. Relevant
safety regulations must also be followed, including generally valid safety-technical,
occupational medicine and road traffic regulations. Own interference and modifications of
the machine exclude the manufacturer’s liability for damages resulting from this.
3. Technical data:
Unit
35M
40eco
Work group
EM
1
1,2
Towing force
kN
35
40
Brake force
kN
37,5
50
Wire rope medium speed
m/s
0,90
0,90
Wire rope maximum length
mm/m
8/115
8/115
mm/m
9/90
9/90
Wire rope length (serial)
mm/m
10/70
11/60
Tractor required power
kW
22-35
25-35
PS
30-48
34-48
Calculated tear force
kN
70
80
Rated strength
N/mm2
70
80
Width
mm
1200
1400
Length
mm
450
470
Height without protective net
mm
1160
1160
Height with protective net
mm
2000
2000
Weight (without wire rope)
kg
245
235
Power take-off RPM
min-1
max 540
max 540
