Uniforest 45M User Manual

22
Pos.
Name
No. of pieces
Number
1
Pulley, small, single
1
502.00.40.0
2
Pulley, small, single 2
1
502.00.42.0
3
Pulley, small, double, wide
2
502.00.43.0
4
BRAKE CABLE KPL
1
502.00.50.0
5
Clutch cable kpl.
1
502.00.55.0
6
Brake belt var.
1
502.06.00.0
7
Brake bolt
1
502.06.12.0
8
Clutch roller
3
502.11.15.0
9
Clutch lever spring
1
502.11.25.0
10
Clutch lever var.
1
5002.05.05.0
11
Activation mechanism
1
5002.05.08.0
12
Brake fork
1
5002.05.15.0
13
Automation system coupler
1
5002.05.41.C
14
Lever link
2
5002.05.43.0
15
Compression spring
1
5002.05.63.0
16
Brake lever var.
1
5002.05.45.0
17
Automation system kpl.
1
5002.05.50.c
18
Clutch plate
1
5006.05.11.0
19
Clutch plate
1
5006.05.12.0
20
Pre-brake bolt
1
5006.05.34.0
21
Compression spring
1
5006.05.36.0
22
Band brake screw Zn
1
5006.05.37.0
23
Pre-brake nut
1
5006.05.38.0
24
Screw M10x45 Zn
1
1000075
25
Screw M8x20 Zn
5
1000051
26
Screw M6x25 Zn
1
1000155
27
Screw M12x50 Zn
1
1000072
28
Hexagon socket screw M8x20
2
1000107
29
Screw M8x55 Zn
2
1000041
30
Screw M8x25 Zn
1
1000052
31
Washer M8 Zn
2
1003473
32
Washer M8 Zn
2
1003465
33
Nut M10 Zn
1
1003461
34
Nut M6 Zn
1
1003712
35
Nut M12 Zn
1
1000142
36
Nut M8 Zn
6
1003460
