Uniforest 45M User Manual

23
Figure 2: 5002.05.15.0 – Brake fork.
Pos.
Name
No. of pieces
Number
1
Fork eye
1
5006.05.16.0
2
Brake tube
1
5002.05.22.0
3
Spring washer
1
5002.05.23.0
4
Brake bush
1
5002.05.24.0
5
Brake spring
1
5002.05.40.0
6
Bolt
1
5006.05.14.0
7
Screw M12x220 Zn
1
1000122
8
Nut M12x1,5 Zn
2
1000150
9
Nut M12 Zn
1
1000149
10
Nut M12 Zn
1
1000142
