Unify OpenStage M3 EX User Guide

82 Appendix
General specifications
Handset
DECT
Bluetooth
Battery
The handset is supplied with the recommended battery. Only an original battery
may be used. Replacement batteries can be ordered if necessary from Unify
Service.
Maximum sound pressure level ac-
cording to TBR10, Annex D
less than 118 dB (A)
Weight incl. battery approx. 100 g
Dimensions (W x H X D) approx. 48 x 127 x 19 mm
DECT standard Supported
GAP standard Supported
No. of channels 60 duplex channels
Radio frequency range 1880-1,900 MHz
Duplex method Time multiplex, 10 ms frame length
Pulse repetition rate 100 Hz
Pulse transmission length 370 µs
Channel grid 1,728 kHz
Bit rate 1152 kbit/s
Modulation GFSK
Language code 32 kbit/s
Transmission power 10 mW, average power per channel
250 mW pulse power
Range Up to 300 m outdoors, up to 50 m indoors
Environmental conditions in
operation
+5 °C to +45 °C, 20 % to 75 % relative
humidity
Radio frequency range 2402-2,480 MHz
Transmission power 4 mW pulse power
Technology Lithium ion (Li-Ion)
Voltage 3.7 V
Capacity 750 mAh
Type for OpenStage M3 and
OpenStage
M3 Plus
V30145-K1310-X363
Type for OpenStage M3 Ex and
OpenStage
M3 Ex Plus
V30145-K1310-X453
