UNIPULSE F701-C 文技术手册 无锡波贸公司 0510-82706452/13861775500
1-2. Rear Panel 面板
AC power input terminal board
线端子
Option space
预留
Guard ground
Frame ground
Control connector
控制
RS-232C connector
LOCK switch
RS232C
开关
SI/F terminal board
Load cell input terminal board
SI/F 线端子
传感入接线端子
AC power input terminal board 线端子
Connect AC power code. The input voltage is 100V
-
240V AC. The frequency is 50/60Hz.
输入 100V - 240V50/60Hz
Guard ground 仪表
This is a guard ground terminal board. Be sure to ground the guard ground terminal to
prevent electric shocks and fail
ures due to static electricity. (The frame and the guard
ground terminal are conducted.) 端子防止干扰
仪表
部是
Frame ground (Functional ground) 功能
This is a F.G. terminal of AC input. (The frame and the
F.G. terminal are conducted.)
地是入电端子仪表部是
Control connector 控制信
This is a connector to input external signals and output control signals. The Input/Output
circuit and internal circuit are photocoupler-insulated electrically. 控制
号输入制信号输出,输入/ I/O 路和路均隔离
The applicable connector is the following (accessory) manufactured by Fujitsu
Component or an equivalent: 座采如下富士公司产品型号产品
Connector :
-
361J024
-
AU
Cover :
-
360C024
-
B
-7-
