5. Installation Instructions
Review all instructions as well as important notes located at the end of this section before starting installation.
Step 1: Mount the Speaker Clamps
Unscrew the allen screws from one side of the clamp to install the clamp. Mount to your handlebars, highway bars or other location and ensure all 4 allen
screws on each clamp are securely tightened. The clamps themselves will tighten to the bar when the speakers are installed.
Step 2: Mount the Speakers
Remove the nut and lock washer only and feed the speaker wire through the clamp hole and mount each speaker to the clamp. Put the lock washer and
nut back on and tighten speaker to clamp. (Flat washer and lock washer go on the bottom). Make sure they are tightly and safely secured without any
movement, but do not over tighten. Run the speaker wires down to where you are going to mount the amplifier, being careful to avoid the engine or any
area that could cause heat or other damage to the wire/vehicle or inhibit your driving ability.
Step 3: Amplifier Power Hook Up
Find a place where you want to mount the amplifier away from direct exposure to the elements such as a tool compartment, under the seat, fork bag,
saddlebag, windshield bag, etc. Most places will be fine, but try to avoid areas that could cause overheating (such as places wrapped in foam or cotton).
Take the BLACK (-) ground wire and run it to the negative (-) battery terminal (or to the vehicle’s chassis where paint has been removed). Take the RED
(+) positive wire and connect it to the positive (+) battery terminal. Take the ORANGE remote-on wire and run it to where you will install your Bluetooth
controller (This will be connected in step 5 when installing the Bluetooth controller). The system will turn on and off using the controller. (It will also turn
Off automatically after 5 minutes when there is no active Bluetooth device connection to prevent battery drain).
(**For non-Bluetooth devices, the orange wire must instead be connected to a switched power source (headlight, tallight, etc). If orange, black & red wires are not connected, system will NOT work.
