OPERATING MANUAL FOR CUBE II
2
2|INTRODUCTION
2.1 | Using of the showcase
Attractive CUBE II showcase is designed to display and maintain the temperature of refrigerated pre-packaged snacks,
such as desserts, sweets, packaged bagels, packaged salads and the like for the purpose of presentation or sales.
Showcase allows easy installation inside the shop and is therefore ideal for pastry shops, bakeries, shops, restaurants,
pumps and the like. Showcase CUBE II may be performed in the serve over and self-service (so called open) design
that allows your customers easy access to the offered goods.
Any use of equipment, employing in excess of this region, including modifications to security or functional
elements without the permission of the manufacturer, is deemed inappropriate purpose. For any damage
resulting from such an activities, the equipment manufacturer is not liable, the risk is covered by the user solely.
2.2 | Improper use
- Showcase is not intended to chill the merchandise on display.
- Showcase is not intended for permanent storage of refrigerated goods.
2.3 | The main parts of the case
The most important part of the exhibition space, which is equipped with glass shelves for arranging snacks, is lit on the
top by the friendly LED lighting. The access to the exhibition space is possible through the back sliding door.
According to the version you ordered front glass are then either full (serve over version) or open (self-service version). See
charter 2.5.
The case is equipped with a ventilation cooling system, automatic defrost and evaporation and electronic control.
Pos. Name Pos. Name
1 Main frame 9 Cover of cooling unit
2 Consoles and glass shelves 10 Controls
3 Bottom decorating panel 11 Adjustable feet
4 Front glass (full or open) 12 Power supply
5 Vents 13 Main vent
6 Top LED lighting 14 Condenser
7 - 15 Side vent
8 Back sliding doors
