3. OPERATION
FRONT PANEL
1) CD DRAWER
2) GRAPHIC LED DISPLAY 128x64
3) IR SENSOR
4) COMMAND BUTTONS
5) MAINS SWITCH (ON THE SIDE)
REAR PANEL
1) MAINS CONNECTOR
2) UNBALANCED OUTPUTS
3) BALANCED OUTPUTS
4) BLUETOOTH ANTENNA
5) USB INPUT
6) DIGITAL INPUTS (TOSLINK, S/PDIF. AES/EBU)
7) DIGITAL OUTPUTS (AES/EBU, S/PDIF, TOSLINK)
1 2 3
4
5
6 7
4
1 2 3 4 5
