Unison Research UNICO CD DUE - Technical Specifications; Digital Inputs

Unison Research

Unico CDDue
69
8. TECHNICAL SPECIFICATIONS
Digital Inputs
1 x USB
Standard: USB 2.0 Audio Class
frequencies: 44.1, 48, 88.2, 96, 176.4, 192, 352.8, 384,
DSD64, DSD128, DSD256
Resolution: 16 to 32 bits
1 x S/PDIF
Sensitivity: 0.5Vpp on 75 Ohms
Sampling frequencies: 44.1, 48, 88.2, 96, 176.4, 192
DSD64 (DoP)
Resolution: 16 to 24 bits
1x AES/EBU
Sensitivity: 2Vpp on 110 Ohms
Sampling frequencies: 44.1, 48, 88.2, 96, 176.4, 192
DSD64 (DoP)
Resolution: 16 to 24 bits
1x Toslink™
Sampling frequencies: 44.1, 48, 88.2, 96 (176.4 and DSD64-
DoP with high efficiency transmitters)
Resolution: 16 to 24 bits
1 x Bluetooth™ Receiver
Standard: BT 3.0
Profiles: A2DP, SSP (HID supported with Android
s martphones through SPP)
Sampling frequencies: 44.1kHz, 48kHz
Resolution: 16 bits
