Unitech HT510 User Manual

5
© 2020 unitech Electronics Co., Ltd. All rights reserved.
unitech is a registered trademark of unitech Electronics Co., Ltd.
All product and company names are trademarks, service marks, or registered trademarks of their respective owners
HT510 User’s Manual
Audio
Built-in microphone, speaker and headphone jack
RFID
UHF RFID : Frequency: 865~868MHz, 902~928MHz
Protocol: EPC global Class 1 Gen 2 ISO 18000-6C/6B
Antenna gain: 3dbi
Output Power : 1-30dbm adjustable
Data Capture Range: 6~8 meters
HF RFID : Frequency 13.56Mhz (NXP PN548)
ISO14443A/B, ISO15693 standard
Regulatory Approvals
NCC, BSMI
I/O Interfaces
USB
MiniUSB (Support OTG)
WLAN
IEEE 802.11a/b/g/n/ac
WWAN
4G LTE TDD-LTD(B38、B39、B40、B41)4G LTE FDD-LTD(B1、B3、
B5、B7、B8)UMTS/HSDPA/HSPA/HSPA+( B1/B2/B5/B8)CDMA2000
1x EV-D0 Rev.A BC0 (800MHz)TD-SCDMA Band
34,39GSM/EDGE/GPRS (850,900,1800,1900MHz)
Expansion Slot
MicroSD x 1, up to 64GB
Power Source
Standard Battery
3.8V, 4500mAH
Enclosure
Weight
385g (including standard battery)
Dimension
L192 x W73.8 x H30 mm
Environmental
Operating temperature
-14°F to 122°F (-10°C to 50°C)
Storage temperature
-4°F to 158°F (-20°C to 70°C )
Relative Humidity
5% ~ 95% ( non-condensing )
Drop test to Concrete
1.5m
Environmental Sealing
IP65
