2. Position the battery pack, making sure the battery contacts are aligned with the
contacts in the compartment and the battery is placed on top of the plastic tab,
as shown in the following illustration.
3. Slide the battery pack into the battery bay while simultaneously pulling the plas-
tic tab and securing clip until the battery clicks into place.
4. Replace the battery compartment cover.
Contacts
Plastic tab
Plastic tab
Securing clip
