Unitech PA760 User Manual

7
© 2019 unitech Electronics Co., Ltd. All rights reserved.
unitech is a registered trademark of unitech Electronics Co., Ltd.
All product and company names are trademarks, service marks, or registered trademarks of their respective owners
PA760 User’s Manual
Regulatory Approvals
CE, FCC, NCC, BSMI, VCCI, TELEC, CCC, SRRC, RoHS, DoC, BQB, GMS, N-Mark compliance
Communication
USB
USB OTG Type C Connector for PC/USB drive
POGO PIN connector for Cradle
WLAN
IEEE802.11 a/b/g/n/ac/d/h/i/r, support fast roaming,
MIMO(2x2)
PAN
Bluetooth
®
5
WWAN
LTE
FDD: Band 1(2100), Band 2(1900), Band 3(1800), Band
4(1700), Band 5(850), Band 7(2600), Band 8(900),
Band 17(700bc), Band 20(800), Band 28(700)
TDD: Band 38(2600), Band 39(1900), Band 41(2500)
*Support Dual Nano SIM Slot
GPS
GPS/GLONASS/Gallileo/Beidou
Others
Support NFC, fingerprint (optional)
Camera and Flash Light
16 MP Rear, 5 MP Front camera (optional)
Power Source
Standard Battery
4000mAh / battery with cover in one piece
Extended Battery
6000mAh / battery with cover in one piece
Enclosure
Weight
Approximately 300g
Dimension
163mm (L) x 17.4mm (H) x 75mm (W)
Environmental
Operating temperature
-4°F to 122°F (-20°C to 50°C)
Storage temperature
-22°F to 140°F (-30°C to 60°C)
Relative Humidity
5% ~ 95% ( non-condensing )
Drop test to Concrete
1.5 meter, 1.8 meter with bumper
Environmental Sealing
IP67

Unitech PA760 Specifications

General

Brand	Unitech
Model	PA760
Category	PDA
Language	English
