How to test United Electric Controls ONE Switch if ohmmeter doesn't work?
If you're having trouble testing United Electric Controls electronic switches using an ohmmeter, an alternative method is to measure the voltage drop across the switch while it is connected to the intended load. This will help you determine whether the switch is open or closed.
Explanation of set point, deadband, and switch mode impact on output.
Info on local LED and IAW™ signal for status and diagnostics.
How to select and set the switch mode for desired operation.
Diagnostic steps for when the unit appears to have no power.
Interpreting VALUE > SET POINT and VALUE < SET POINT messages.
Wiring IAW™ output to PLC, DCS, or PC inputs.
Wiring 100 mA output to PLC, DCS, or PC inputs.
Wiring for 15A solid-state relay output.
General| Product Series | ONE Series |
|---|---|
| Enclosure Rating | NEMA 4X, IP66 |
| Switch Type | SPDT |
| Hazardous Location Approvals | Class I Div 1 & 2 Groups B, C, D; Class II Div 1 & 2 Groups E, F, G; Class III; ATEX, IECEx |
| Housing Material | 316 Stainless Steel |
| Electrical Rating | 0.5 A 125 VDC |
| Setpoint Accuracy | ±1% of range |
| Operating Temperature Range | -40 to 185°F / -40 to 85°C (Model Dependent) |
| Process Connection | 1/4" NPT, 1/2" NPT (Model Dependent) |
| Wetted Materials | 316 stainless steel, Viton |
| Approvals | UL, CSA, ATEX, IECEx |
| Category | Pressure and Temperature Switches |
