Model 9004 Model 9005
Automatic Power-Off – after 10 minutes approx.
Temperature Range: 23° C % 5° C
– Operation 0 … 40° C
– Storage –10° C … +60° C
Height abover MSL: up to 2000 m
Security: EN 61010/IEC 61010
Rated voltage towards ground: max. 600 V
Overvoltage class: II up to 600 V
III up to 300 V
Contamination degree: 2
Power Consumption max.: 10 mA / 0.1 W max 1.9 mA / 6 mW
Power Supply: 9 V Battery IEC 6LR61 2x1.5V Batteries IEC LR6
Dimensions*: 165 x 78 x 50 mm 165 x 78 x 50 mm
Weight*: 340 g approx. 380 g approx.
* Dimensions and weight incl. Protective Rubber Holster
Model 9004: Measurement Ranges:
DC Voltage
Meas. Range
200 mV
2000 mV
20 V
200 V
600 V
Accuracy
% (0.8 % rdg
+ 2 digits)
Resolution
0.1 mV
1.0 mV
10 mV
100 mV
1 V
Overload prot.
600 V
AC/DC
Input-
Resistance
10 MV
AC Voltage (50 … 200 Hz)
Meas. Range
200 mV
2000 mV
20 V
200 V
600 V
Accuracy
% (1.5 % rdg
+ 3 digits)
Resolution
0.1 mV
1.0 mV
10 mV
100 mV
1 V
Overload prot.
600 V
AC/DC
Input-
Resistance
10 MV
DC Current
Meas. Range
20 mA
200 mA
15 A
Accuracy
% (1.2 % rdg + 2 Digits)
% (1.2 % rdg + 2 Digits)
% (2.0 % rdg + 3 Digits)
Resolution
10 µA
100 µA
10 mA
Overload prot.
200 mA/250 V
12,5 A/250 V
Load-
Voltage
200 mV
AC Current (50 … 200 Hz)
Meas. Range
20 mA
200 mA
15 A
Accuracy
% (1.2 % rdg + 3 digits)
% (1.2 % rdg + 3 digits)
% (2.0 % rdg + 3 digits)
Resolution
10 µA
100 µA
10 mA
Overload prot.
200 mA/250 V
12,5 A/250 V
Load-
Voltage
200 mV
Input current 10 … 15 A for a maximum of 15 seconds
Input current 10 … 15 A for a maximum of 15 seconds
