22
Resistance
Diode Test
Display of forward voltage
Test current 1 mA approx. · Open circuit voltage 3 V approx.
Continuity Test
Signal sound if resistance value smaller than 300 V approx.
Open circuit voltage 2.5 V approx..
Meas. Range
200 V
2 kV
20 kV
200 kV
2000 kV
Accuracy
% (0.8 % rdg
+ 2 digits)
Resolution
0.1 V
1.0 V
10 V
100 V
1 kV
Overload prot.
250 V
AC/DC
Open Circuit
Voltage
< 3 V
Model 9005: Measurement Ranges
DC Voltage
Meas. Range
320 mV
3.2 V
32 V
320 V
600 V
Accuracy
% (0.5 % rdg
+ 2 digits)
Resolution
0.1 mV
1.0 mV
10 mV
100 mV
1 V
Overload prot.
600 V
AC/DC
Input-
Resistance
5 MV*/
10 MV
AC Voltage (50 … 400 Hz)
Meas. Range
3.2 V
32 V
320 V
600 V
Accuracy
% (1 % rdg
+ 5 digits)
Resolution
1.0 mV
10 mV
100 mV
1 V
Overload prot.
600 V
AC/DC
Input-
Resistance
5 MV*/
10 MV
DC Current
Meas. Range
320 µA
3200 µA
32 mA
320 mA
15 A
Accuracy
% (1.0 % rdg + 2 digits)
% (2.0 % rdg + 2 digits)
Resolution
0.1 µA
1 µA
10 µA
100 µA
10 mA
Overlaod prot.
500 mA/250 V
12,5 A/250 V
Load-
Voltage
1,6 V
75 mV
AC Current (50 … 400 Hz)
Meas. Range
320 µA
3200 µA
32 mA
320 mA
15 A
Accuracy
% (1.5 % rdg + 3 digits)
% (2 % rdg + 3 digits)
Resolution
0.1 µA
1 µA
10 µA
100 µA
10 mA
Overload prot.
500 mA/250 V
12,5 A/250 V
Load-
Voltage
1,6 V
75 mV
Input current 10 … 15 A for a maximum of 15 seconds
Input current 10 … 15 A for a maximum of 15 seconds
* Auto AC/DC
* Auto AC/DC
