Apollo x8p Hardware Manual Specifications 38
ANALOG I/O
Microphone Inputs 1 – 8
Frequency Response 20 Hz – 20 kHz, ±0.05 dB
Dynamic Range 122 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 4.9 dBu) -114 dB (0.00020%)
Maximum Input Level (PAD on) 26 dBu
Default Input Impedance 5.5k Ohms (variable via Unison plug-ins)
Gain Range +10 dB to +65 dB
Pad Attenuation (switchable per input) 20 dB (variable via Unison plug-ins)
Phantom Power +48V (switchable per mic input)
Connector Type XLR Female, pin 2 positive (Combo XLR/TRS)
Hi-Z Inputs 1 – 2
Frequency Response 20 Hz – 20 kHz, ±0.04 dB
Dynamic Range 121 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 11.2 dBu) -111 dB (0.00028%)
Maximum Input Level 12.4 dBu
Default Input Impedance 1M Ohms (variable via Unison plug-ins)
Gain Range +10 dB to +65 dB
Connector Type ¼” Female TS Unbalanced
Line Inputs 1 – 8
Frequency Response 20 Hz – 20 kHz, ±0.04 dB
Dynamic Range 123 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ 23 dBu) -113 dB (0.00022%)
Maximum Input Level 24 dBu
Input Impedance 10K Ohms
Gain Range +10 dB to +65 dB
Connector Type (8) ¼” Female TRS Balanced (Combo XLR/TRS)
(1) Female DB25 (Tascam wiring), Normalled
Line Outputs 1 – 8
Frequency Response 20 Hz – 20 kHz, ±0.07 dB
Dynamic Range 127 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS) -119 dB (0.00011%)
Maximum Output Level 24 dBu
Output Impedance 100 Ohms
Connector Type Female DB25 (Tascam wiring)
Monitor Outputs 1 – 2
Frequency Response 20 Hz – 20 kHz, ±0.06 dB
Dynamic Range 129 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS) -118 dB (0.00012%)
Maximum Output Level 24 dBu
Output Impedance 100 Ohms
Connector Type ¼” Female TRS Balanced
Stereo Headphone Outputs 1 – 2
Frequency Response 20 Hz – 20 kHz, ±0.05 dB
Dynamic Range 125 dB (A–weighted)
Total Harmonic Distortion + Noise Ratio (1 kHz @ -1 dBFS) -102 dB (0.00080%)
Maximum Output Power (into 300 ohm load) 150 mW RMS
Connector Type ¼” Female TRS Stereo
