Fruit Mania Operation Manual
21
9.3 Button assembly
9.4 Marquee assembly
No. Part No. Code Name Qty
1 N102-609-000 20641202A006 Bumper block 2
2 N102-219-000 20241202A023 Button fix base 1
3 N102-220-000 20241202A024 Micro fix board 2
4 N102-221-000 20241202A025 Back-moving spring 4
5 N102-610-000 20641202A007 Gold coin button 1
No. Part No. Code Name Qty
1 N102-222-000 20241202A026 Vacuum form fix board 1 2
2 N102-223-000 20241202A027 Vacuum form fix board 2 3
3 N102-224-000 20241202A028 Mask board 1
4 N102-225-000 20241202A029 Marquee pad 2
5 N102-522-000 20341202A021 Marquee install board 1
6 N102-611-000 20641202A008 Marquee vacuum form 1
7 N102-226-000 20241202A031 Light bar fix assembly 4
