Fruit Mania Operation Manual
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install
outdoors.
z Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid
z Place the unit on a dry level surface
z Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area:250mm
Play area： 500mm
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level
the game
. If the game is installed on an unsuitable floor, it could cause game
malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters
off the ground by 5mm. Repeat the same for all levelers.
Play area
