Lane Master Manual
07/19/2017
7
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
1. Following accessories
*For bowling ball, it is suggested to take 2 for each lane.
NOTE: Part models are subject to change without notice.
No. Part No. Code Name Qty
1 L105-801-000 25300171002
Key
(171)
6
2 L105-803-000 25300172002
Key
(171B)
1
3 L105-802-000 23301010020 Power cord 1
4 L105-529-000 21901000013
Fuse
(Φ5×20mm
T10A)
1
5 L105-804-000 41440000173 Manual 1
6 L105-805-000 20611605027 Bowling ball 4
7 L105-806-000 20211605A002
Blank door 1
8 L105-525-000 21503000053
Sensor
SW(receive)
2
Please refer
to P20
Disassemble
the lane
sensor
9 L105-526-000 21503000052
Sensor
SW(send)
2
