9.3 Decals
No.
Part No. Draw No. Name Material Qty
1 P113-701-000
20541122S001
Marquee decal Plastic 2
2 P113-702-000
20541122S002
Control decal 1 Plastic 1
3 P113-703-000
20541122S003
Control decal 2 Plastic 1
4 P113-704-000
20541122S004
Both side decal 0.3PVC 2
5 P113-705-000
20541122S005
Monitor decal 0.3PVC 1
6 P113-706-000
20541122S006
L side decal 0.3PVC 1
7 P113-707-000
20541122S007
R side decal 0.3PVC 1
8 P113-708-000
20541122S008
Orange fish mech right side decal
0.3PVC 1
9 P113-709-000
20541122S009
Blue fish mech right side decal 0.3PVC 1
10 P113-710-000
20541122S010
Red fish mech right side decal 0.3PVC 1
11 P113-711-000
20541122S011
Green fish mech right side decal 0.3PVC 1
12 P113-712-000
20541122S012
Lower hook decal White PVC100u
4
13 P113-713-000
20541122S013
Base decal 0.3PVC 1
14 P113-714-000
20541122S014
Orange fish mech left side decal 0.3PVC 1
15 P113-715-000
20541122S015
Blue fish mech left side decal 0.3PVC 1
16 P113-716-000
20541122S016
Red fish mech left side decal 0.3PVC 1
17 P113-717-000
20541122S017
Green fish mech left side decal 0.3PVC 1
18 P113-730-000
25600000023 Coin mech decal δ0.2plastic 4
19 P113-731-000
25600000034 Ticket decal White PVC100u
4
20 P113-732-000
25600000035 Fork decal White PVC100u
4
2
1
3
4
6
7
8
12
19
16
10
11 17
8
14
13
15
9
20
18
