Univex 1000S User Manual

CARRIAGE SLIDE ASSEMBLY
FIGURE 11
ITEM N
o. PART No. DESCRIPTION QTY.
1. F4100872 Pivot, Front blocking bar 1
2. F3030504 Washer, Rubber 2
3. F3030502 Washer, Rubber 3
4. F4070209 Bar, Carriage Slide 1
5. F7003339 screw, Socket Head Cap M6-1.0 x 25 2
6. F4100800 Nut, Jam M12-1.75 2
7. F7003338 Screw, Socket Head Cap M6-1.0 x 16 3
8. F4070309 Bar, Carriage Slide 1
*9. F405FC08 Plate, Tilt Lock Bar 1
*10. F4100032 Bar, Tilt Lock 1
*11. F4100860 Bushing, Tilt Lock Bar 1
*12. F405FC06 Plate, Tilt Lock Bar 1
13. F405FC10 Fork, Tilt Lock 1
14. F405CB24 Stop, Tilt Lock Fork 1
15. F7003035 Screw, Socket Head Cap M5-0.8 x 12 2
16. F4100195 Screw, Nylon Tipped 2
17. F7000492 Nut, Jam M10-1.50 2
18. F7003608 Retaining Ring 1
19. F7000245 Screw, Socket Head Set M6-1.0 x 8 1
20. F4100253 Pin, Arm Pivot 1
21. F4100866 Pin, Tilt Lock Fork 1
22. F7000236 Screw, Socket Head Set M5-0.8 x 10 1
23. F4101233AC Knob, Tilt Lock (aluminum) 1
Knob, Tilt Lock (plastic)
24. F3031223 Spring 1
25. F4100870 Shaft, Tilt Lock 1
26. F4100086 Bushing, Tilt Lock Shaft 1
27. F4020052 Arm, Carriage 1
28. F7004003 Nut, Jam M8-1.25 1
29. F4100195 Screw, Socket Head Set M8-1.25 x 18 1
30. F7001769 Screw, Socket Head Set M10-1.5 x 25 1
31. F4010043 Slide, Carriage Support 1
32. F3030504 Washer 2
33. F7001357 Screw, Socket Flat Head M8-1.25 x 25 1
34. F3030323 Bearing 1
35. F3031266 Spring 1
36. F4100870 pivot, Rear, Blocking Bar 1
* Items 9, 10, 11, and 12 are all part of a welded assembly and cannot be purchased separately.
page 21
