Univex 1000S User Manual

CARRIAGE ASSEMBLY
FIGURE 12
ITEM N
o. PART No. DESCRIPTION QTY.
1. F4020126 Carriage 1
2. F4100780 Pad, Nylon 5
3. F4020282 Plate, Last Slice Device 1
4. F4090302 Knob (plastic) 3
F4090361 Knob (plastic, black)
5. F3040125 Plug 3
6. F3030814 Bushing 2
7. F4100776 Nut, Acorn M5-0.8 1
8. F70035 Screw, Socket Head Set M5-0.8 x 12 1
9. F4100776 Pin, Rubber 3
10. F4100780 Pin, Nylon 2
11. F4100034 bar, Arm Slide 1
12. F4090325 Handle, Last Slice Device Feed Grip 1
F4090173 Handle, Last Slice Device Feed Grip (plastic)
13. F4100862 Shaft, Last Slice Device 1
14. F4090325 Arm, Last Slice Device 1
15. F7002749 Pin 1
16. F4100919 Washer, Nylon 1
17. F406AD03 Spacer, Last Slice Device 1
18. F405FC12 Plate, Protection 1
19. F7000634 Screw, Slotted Flat Head M5-0.8 x 12 4
20. F7001759 Screw, Socket Head Set M8-1.25 x 25 2
21. F4100896 Pin 9
22. F4090321 Handle (aluminum) 1
F4101236AC Handle (plastic)
23. F7002463 Screw, Slotted Flat Head M10-1.5 x 26 1
24. F405AC04 Bar, Handle 1
25. F7003335 Screw, Socket Flat Head M6-1.0 x 15 2
26. F7001758 Screw, Socket Head Set M8-1.25 x 35 2
27. F7009008 Nut, M8-1.25 2
28. F7003808 Washer, M8 2
Page 23
