Univex 1000S User Manual

SLICE THICKNESS CONTROL
FIGURE 13
ITEM N
o. PART No. DESCRIPTION QTY.
1. F4020268 Fence 1
2. F4020368 Block, Fence Mounting 1
3. F7000266 Screw, Socket Head Set M10-1.5 x 16 2
4. F3040127 Plug 2
5. F4090003 Boot, Rubber 1
6. F4100791 Shaft, Slice Control 1
7. F3030809 Bushing 2
8. F405CB32 Gibb 1
9. Bracket, Switch Front (1000s only) 1
10. Switch (1000s only) 2
11. Screw, Socket Head Cap M6-1.0 x 18 2
12. Bracket, Switch Rear (1000s only) 1
13. Screw, Socket Head Cap M6-1.0 x 20 1
14. F700013A Screw, Socket Head Cap M6-1.0 x 30 1
15. F7001748 Screw, Slotted Set Brass M6-1.0 x 20 1
16. F7000462 Nut, M6 2
17. F403E010 Slide, Slice control 1
18. F3031306 Screw, Socket Head Set M6-1.0 x 6 2
19. F7003338 Screw, Socket Head Cap M6-1.0 x 16 1
20. F3031236 Spring 1
21. F700013A Screw, Socket Head Cap M6-1.0 x 12 1
22. F7004008 Nut, M8 1
23. F7007008 Washer, flat M8 1
24. F4100525 Cam Follower 1
25. F4100332 Pin 1
26. F7001745 Screw, Socket Head Set M6-1.0 x 8 1
27. F405CB22 Plate, Arm Release 1
28. F7000634 Screw, Slotted Flat Head M5-0.8 x 12 1
29. F4100256 Shaft, Graduated Knob 1
30. F7001435 Snap Ring 1
31. F4090163 Cam 1
32. F4100102 Shaft, Cam Follower 1
33. F7003726 Screw, Slotted M4-0.7 x 10 2
34. F7002308 Washer, Toothed M8 1
35. F7003339 Screw, Socket Head Cap M6-1.0 x 25 1
36. F2V30012 Knob, Graduated (plastic) 1
F4101234AC Knob, Graduated (plastic)
37. F7000236 Screw, Socket Head Set M5-0.8 x 16 2
38. F4090104 Ring, Graduated Knob 1
39. F4100100 Nut, M12 1
40. F7003536 Screw, Socket Head Set M5-0.8 x 8 1
41. F700263F Washer, Spring 1
42. F4100106 Bushing 1
43. F3040167 Plug 2
44. F700175B Screw, Socket Head Set M8-1.25 x 30 2
45. F7004008 Nut, M8-1.25 2
46. F7003808 Washer, M8 2
Page 25
