Foot
(includes leveling pads
qty 2)
Leg
(qty 3)
Crossbar rail
(inside crossbar ends
qty 3)
Crossbar end
(qty 3)
Side bracket
(qty 2)
Adhesive pad
(qty 17)
Keypad
one of two types
(qty 1)
or
WHAT NEEDS TO BE PULLED FROM THE FRAME BOXES:
(Note: Boxes may include extra hardware)
Unbox your desktops You’ll need these tools
qty one power cable
qty two short leg cables
qty one long leg cables
Cables
All of the parts that you need for your 3-leg frame
come shipped in these two boxes, shown here.
As you unpack your boxes,
these are the parts you will need.
Small foot
(includes leveling pad
qty 1)
Corner
crossbar end
(qty 1)
Open-end rail
(qty 1)
Corner bracket
(qty 1)
Control box
(qty 1)
M6x14 screw
(qty 32)
M6x35 screw
(qty 4)
M6x10 screw
(qty 16)
#10x5/8’’
Wood screw
(qty 25)
#10-24x5/8’’
Machine screw
(qty 13)
Cable clip
(qty 15)
Main desktop
(laminate, bamboo,
or rubberwood)
(qty 1)
Return desktop
(laminate, bamboo,
or rubberwood)
(qty 1)
Support bracket
(qty 2)
Please recycle
Stand up for your health • upliftdesk.com • 800-349-3839
09.001.06.0260
FRM300~BLK
3rd Leg Kit - Black
Stand up for your health
upliftdesk.com • 800-349-3839
Designed in USA. Made in China.
Please recycle
09.001.06.0004
FRM200~BLK
2-Leg Frame - Black
2-leg
frame
3rd leg kit
Philips Head Screwdriver
and/or Power Drill
Tape MeasureAllen wrench
(included)
1
2
3
4
5
6
7
8
9
10
11
12
14
15
13
16 17 17 18
20
21
3. PARTS LIST
a b
To Next Page
