Installing control wires for humidifier control
If control of the humidifier is desired, the 2 wires connecting the original humidistat needs to be
connected to the 2 terminals marked 'H1' and 'H2' on the thermostat.
The original humidistat should be removed or set to 'OFF' position.
Noted: The 2 humidifier control terminals 'H1' and 'H2' are electrically isolated from the Heat/Cool
terminals.
30
Humidistat should be
OFF or disconnected
