check once again that bearing clearance is now acceptable.

Figure 27. Lever-Type Front Fork

1 - Protective washer 9 - Bearing nut 17 - Fork leg left tube

2 - Seal

10 - Upper radial-thrust ball

bearing

18 - Spring-hydraulic shock

absorber

3 - Fork crosspiece 11 - Tightening nut 19 - Brake drum cover tie rod

4 - Nut of steering column stem 12 - Washer 20 - Wheel lever

5 - Supporting washer 13 - Leg housing with headlight 21 - Moving washer

6 - Spring washer bracket 14 - Steering column bridge 22 - Steering column bridge

7 - Clamping bolt 15 - Fender clip 23 - Lower radial-thrust ball

8 - Steering column stem 16 - Front fender bearing
